ProLine Series BR138001050B 1-3/8 in. O.D. x 1 in. I.D. x 50 ft. Braided Clear Vinyl Tubing

Description

ProLine Series BR138001050B 1-3/8 in. O.D. x 1 in. I.D. x 50 ft. Braided Clear Vinyl Tubing The 1-3/8 in. O.D. x 1 in. I.D. x 50 ft. Braided Clear Vinyl Tubing Braided Clear Vinyl Tubing from ProLine is has 4-times the working pressure of single wall PVC tubing. This tubing is the perfect choice for severe operating conditions. Trimming or cutting is easy. This tubing can be connected using barbed fittings and connectors then secured with hose or wire clamps. Polyvinyl chloride reinforced with polyester braiding Resistant against acids, alkalis and many solvents Flexible Good for hydraulic, pneumatic and vacuum lines Hardness: shore A, durometer 83 plus/minus 3 Handles a wide array of chemicals, gas and liquids Dimensions Actual inside diameter (in.) 1 Actual outside diameter (in.) 1.375 Nominal Inside Pipe Diameter (In.) 1″ Pipe Wall Thickness (In.) .375 Product Length (ft.) 50 ft Details Application Air, Non-Potable Water Color Family Clear Color/Finish Clear Connectivity Barb Material Vinyl Maximum Flow Rate (gallons per minute) 35 Maximum working pressure (psi) 250 Maximum Working Temperature (F) 175 Minimum working temperature (F) -40 Pack Size 1 Pipe Features Chemical Resistant, Corrosion Resistant, Flexible Pipe or Fitting Product Type Pipe & Tubing Product Weight (lb.) 15.55 lb Additional Resources From the Manufacturer Warranty Installation Guide
